ECL10 Series
£0.00
SKU: ECL10 Series
The ECL10 series is a range of single output AC-DC power supplies that delivers 10W
of power and offers output voltages ranging from 3.3V to 48V. The ECL10 series can be
supplied as PCB mount open frame (suffix -P), PCB mount encapsulated device (suffix -E), or
as open frame chassis mount (suffix -T) requiring JST PHR-2 & PHR-3 mating connectors &
crimps. The ECL10 has IEC Class II construction and a no-load input power less than 0.3W.
Single voltage outputs from 3.3V to 48VDC
Universal input range 85-264VAC
3kVAC input to output isolation
<0.3W no load input power
EN55032 Class B conducted and radiated emissions
IEC62368-1 ITE safety agency approvals
IEC Class II insulation rating
Overvoltage, overload, and short circuit protection
-20°C to +70°C operating temperature
3 year warranty
