PSNCL Series
£0.00
SKU: psncl
AC Inrush Current Limiters. Single phase 220/240VAC, 12A & 16A rating suitable for Inductive and Capacitive loads.
Key Applications:-
• Inductive and capacitive loads
• Isolating transformers
• Protects against unintended operation of fuse or cct breaker
• Allows for smaller cct breakers
• Reduction of cable cross section possible
Features:-
• 12 A & 16 A versions available
• DIN-Rail Mounting
• Screw Terminals AWG20 - 12 (0.5 - 4 mm²)
• Integrated Bypass Relays, no simple NTC-Solution
• Limiting Peak current: 45 A for 100 - 500 ms
