Q Series 0.5W HV DC-DC
£0.00
SKU: Q Series 0.5W HV DC-DC
Input voltage can be 5V, 12V, 15V, or 24V. Output voltages from 100VDC to 10,000VDC
The Q Series is a broad line of ultra-miniature, high reliability DC to HV DC converters supplying up to 5,000 volts in only 0.125 cubic inches and up to 10,000 volts in only 0.614 cubic inches. Input voltage can be 5V, 12V, 15V, or 24V. The output is directly proportional to the input voltage and is linear from <0.7V input to maximum input voltage, allowing for DC-HVDC CONVERTER an adjustable output voltage. Output is load dependent. Isolation permits <±500V bias on output return and output power is 0.5 watt.
