TBA 1 HI Series
£0.00
SKU: TBA 1 HI Series
The TBA 1HI is a 1 Watt DC/DC SIP converter series which is specifically designed to offer a low-cost solution with no concession on quality and lifetime. The new design improves on the industry standard features and offers an integrated continuous short circuit protection circuit, an operating temperature range from –40°C to 85°C without derating and I/O-isolation of 3'000 VDC. It offers a broad application range in any space and cost critical application.
• Continuous short circuit protection
• I/O isolation: 3’000 VDC
• Operating temperature range -40 to +85 °C without derating
• Input voltage ranges (±10%): 5, 12, 24 VDC
• High efficiency up to 82%
• SIP-7 package
• Unregulated outputs
• 3-year product warranty
