TDN 3WISM Series
SKU: TDN 3WISM-1
3 Watts single and dual output, 4:1 input range, Ultra compact SMD package
13,2 x 9,1 x 10,2 mm
The TDN 3WISM Series comprises 3 Watt fully regulated, high performance DC/DC converters.
They come in a compact cubical package of only 1.23 cm3. Full load operation is reliable up tp 70°C environment temperature.
With 1’600 VDC I/O-isolation voltage, external On/Off, and short current protection they cover a wide range of application when space is limited.
The input of the converters is designed for a wide voltage range (4:1) and minimum load is not required. The functional I/O-isolation system is designed to meet IEC/EN 62368-1 with a test voltage (60 s) of 1600 VDC.
