TEN 10 Series
£0.00
SKU: TEN 10 Series
The TEN 10 series is a family of high performance 10W DC/DC converters in a com-pact 2” x 1” low profile package with industry standard footprint. A high efficiency allows a wide operating temperature range of –40°C to +85°C. A built-in EMI filter is built in to meet EN 55022, class A without any external components. Further standard features include over voltage protection and short circuit protection. Typical applications for these converters are battery operated equipment, instrumentation, distributed power architectures in communication and industrial electronics, everywhere where isolated, tightly regulated voltages are required.
- Wide 2:1 input range
- High power density
- Operating temperature range – 40°C to +85°C
- Indefinite short circuit protection
- I/O isolation 1500 VDC
- Input filter to meet EN 55022, Class A and FCC, level A without external components
- Industry standard pinout
- Shielded metal case with insulated baseplate
- High reliability, MTBF >1 million hours
- 3-year product warranty
