TEN 30 Series
£0.00
SKU: TEN 30 Series
The TEN 30 series is the latest generation of high performance DC/DC converter modules setting a new standard concerning power density. This product with 30W comes in an encapsulated, shielded metal package with a footprint of only 2.0” x 1.0”. All models have wide 2:1 input voltage range and precisely regulated, isolated output voltages. Advanced circuit topology provides high efficiency up to 91% which allows an industrial operating temperature range of –40°C to +80°C (with derating). Further features include remote On/Off, adjustable output, under-voltage lockout and over temperature protection. Typical applications for these converters are mobile equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.
• 2" x 1" x 0.4" metal package
• Wide 2:1 input range
• Very high efficiency up to 91%
• Operating temperature range -40°C to +80°C
• Over-temperature protection
• I/O isolation 1600 VDC
• Adjustable output voltage
• Remote On/Off
• 3-year product warranty
