TEN 40UIR Series
£0.00
SKU: TEN 40UIR
The TEN 40UIR is a series of high-performance DC/DC converters with an ultra- wide 12:1 input voltage range and a power output of 40 watt. The TEN 40- UIR comes in a compact, fully encapsulated 2”x1” housing for highest reliability and effective cooling. Thanks to its dedicated holdup capacitor connection, the
TEN 40UIR meets extended holdup-time requirements without the need for bulky input capacitors. The TEN 40UIR is EN 50155 certified for rolling stock applications, EN 61373 certified for resistance against mechanical shock and vibration and EN 45545-2 certified for fire behaviour. The TEN 40UIR also comes with IEC/EN/UL 62368-1 safety approvals for use in a wide range of demanding industrial applications.
• Compact 2”x1” housing
• Ultra-wide 12:1 input voltage range: 9–75, 14–160 VDC
• –40°C up to +70°C natural convection cooling without derating
• EN 50155, EN 45545-2 and EN 61373 certified
• Dedicated holdup capacitor connection
• Fully encapsulated
• 3000VDC I/O isolation
• Remote on/off and trim function
• Protection against short-circuit (SCP), overvoltage (OVP) and overtemperature (OTP)
• 3-year product warranty
