TEN 6 WIRH Series
£0.00
SKU: TEN 6 WIRH Series
The TEN 6WIRH is a series of 6 watt railway-certified DC/DC converters with reinforced I/O isolation for highest reliability in harsh environments. The proven and certified design guarantees highest resistance against thermal shocks, moisture, mechanical shocks, and vibration. The TEN 6WIRH comes with additional EN 62368-1 safety approvals for IT equipment and EN 45545-2 certification for fire behaviour. Thanks to its favourable operating temperature range of -40°C to +85°C without derating (depending on the model), the TEN 6WIRH presents a first choice for demanding applications.
• Fully encapsulated DIP-24 package
• 3000 VAC I/O isolation (reinforced)
• 4:1 input voltage range: 36 – 160 VDC
• EN 50155 and EN 61373 certified
• Internal class A EMI filter
• -40°C up to +85°C without derating
• EN 45545-2 fire performance
• Remote on/off function
• Undervoltage lockout (UVLO), short-circuit protection (SCP), and overvoltage protection (OVP)
• 3-year product warranty
