40 Watts single output, 4:1 input range up to 160VDC, remote on/off, High power block with excellent thermal convection
The TEQ-40WIR Series is a family of isolated high performance dc-dc converter modules with ultra-wide 4:1 input voltage ranges which come in a rugged metal case.
These converters are suitable for a wide range of applications, but the product is designed particularly also for industrial applications where often no PCB mounting is possible but the module has to be mounted on a chassis.
A very high efficiency and the heat sink construction allows an operating temperature up to +83°C with natural convection cooling without power derating and up to +92ºC with power derating.
Further features include under voltage lockout, over temperature protection and short circuit protection.
