TEQ160 WIR Series
£0.00
SKU: TEQ160 WIR
The TEQ 160WIR Series is a family of isolated high performance DC/DC converter modules with ultra-wide 4:1 input voltage ranges which come in a rugged, sealed metal case. These converters are suitable for a wide range of applications, but the product is designed particularly also for industrial applications where often no PCB mounting is possible but the module has to be mounted on a chassis. A very high efficiency and the overall heatsink construction allows an operating temperature up to +75°C with natural convection cooling without power derating and up to +90°C with power derating. Further features include output voltage trimming, Remote On/Off and under voltage lockout. The very wide input voltage range makes these converters also an interesting solution for battery operatedsystems.
• High power block with excellent thermal convection
• Operating temperature -40°C to +75°C without derating
• Increased shock & vibration resistance
• Ultra wide 4:1 input voltage range
• EN 50155 approval for railway applications
• Excellent efficiency up to 90%
• Input filter meet EN 55022, class A
• I/O insulation 1591 VAC
• Under voltage lock-out circuit
• 3-year product warranty
