TER 100WIR Series
£0.00
SKU: TER 100WIR Series
The TER 100WIR is a series of high-performance 100 Watt DC/DC converters with a wide 4:1 input voltage range. The TER 100WIR comes in a compact, fully encapsulated quarter-brick package for highest reliability. The converter features continuous short-circuit protection and automatic recovery from over-temperature events, guaranteeing safe and dependable operation. The TER 100WIR is EN 50155 certified for rolling stock applications, EN 61373 certified for mechanical shock and vibration, and EN 45545-2 certified for fire behaviour. It comes with IEC/EN/UL 62368-1 safety approvals.
• Wide 4:1 input range
• EN 50155 and EN 61373 certified
• EN 45545-2 fire behaviour
• Encapsulated quarter-brick (2.3”x1.45”x0.5”) package
• –40°C up to +80°C operating temperature without derating
• Up to 4'242 VDC I/O isolation
• Remote on/off and trim function
• Undervoltage lockout (UVLO), short-circuit protection (SCP), overvoltage protection (OVP) and overtemperature protection (OTP)
• 3-year product warranty
