TIM 2 Series
SKU: TIM 2-1-1
2 Watts single & dual output, DIP-16-package, –I/O isolation 5000 VAC rms rated for 250 VAC rms working voltage, Low leakage current
The TIM 2 series is a range of 2 Watt DC/DC converters in compact DIP-16 package and with reinforced isolation of 5000 VAC rms for medical applications.
With a low leakage current of less than 2 μA the converters are predestined to insulate electrical equipment from the applied parts to patient (BF classification).
The models are approved to IEC/EN/ES 60601-1 3rd edition for 2xMOPP up to an altitude of 5000m and come along with an ISO 14971 risk management file.
