TMDC10 Series
£0.00
SKU: TMDC10
The TMDC 10 series (10 Watt) is the latest additions to Traco Power's existing
TMDC line of Industrial DC/DC off-board modules. Equipped with integrated
filters which limit conducted and radiated emissions (EN 55032 class A) but
also increase the modules EMC immunity (EN 55035), this series is suitable for
many harsh industrial applications which require increased EMC and isolation
(3000 VDC I/O-isolation) capabilities.
The modules come in fully encapsulated 3.11" x 1.34" x 0.87" plastic package
and feature a temperature range from –40° to 80°C without derating. All
models have an ultra wide 4:1 input voltage range from either 9-36 VDC or
18-75 VDC and fully regulated outputs. Latest IT safety certifications (UL
62368-1) and DC-OK and remote on/off functions complete the package to
provide an ideal solution for many harsh industrial applications.
• Fully encapsulated chassis mount modules
• Harsh industrial EMC capabilities: Integrated filters for emission (EN 55032) & immunity (EN 55035)
• Ultra wide 4:1 input voltage range: 9-36 and 18-75 VDC
• Operating temperature range -40 to +80 °C without derating
• I/O-isolation 3’000 VDC
• Protection against overload, undervoltage and short circuit
• DC-OK (LED) and Remote On/Off function
• IEC/EN/UL 62368-1 safety approvals
• 3-year product warranty
