TMR 6WIR Series
SKU: TMR 6WIR-1
6 Watts single & dual output, 4:1 input range, remote on/off, SIP-8 metal case EN 50155 and UL 60950-1 certification
The TMR 6WIR series is a set of 6 Watt DC/DC converters in a SIP-8 metal case.
They operate up to 60°C environment temperature at full load and up to 80°C
with a 50% load derating.
With EN 50155 and UL 60950-1 certification, 3’000 VDC I/O-isolation voltage, external On/Off, overload and short current protection they cover a wide range of application when space is limited.
The input of the converters is designed for a wide voltage range (4:1) and minimum load is not
