TON 15 WI Series
£0.00
SKU: TON 15WI
The TON15WI series is a generation of high performance 15W DC-DC converters with ultra-wide input voltage range and precisely regulated output voltage. The ultra com-pact open frame design with industry standard pin-out provides the designer now a 50% smaller, cost efficient alternative to existing 10 to 15W converters in the market. Built-in filters for both input and output minimize the need for external filtering. Further features include remote On/Off, output voltage trimming, over voltage protec-tion and short circuit protection. Typical applications are distributed power systems, instrumentation and industrial electronics, everywhere where space on the PCB is a critical factor.
- Ultra compact 15W converter
- Ultra wide 4:1 input voltage range
- Cost efficient open frame design with industry standard pin-out
- Surface-mount (SM) and through-hole version
- I/O isolation voltage 2250V, rated for basic insulation
- Extended operating temperature range –40°C to +85°C
- Remote On/Off
- Lead free design, RoHS compliant
- 3-years product warranty
