TPP 150A-J Series
SKU: TPP 150A-J-1
Single output 150 Watts, Open frame 150 W power supply with JST connection in 2.0” x 4.0” package, Low leakage current <75 µA rated for BF applicationsThe TPP 150A-J series of 150 Watt AC/DC open frame power supplies feature a reinforced double I/O isolation system according to latest medical safety standards (60601-1 3rd edition, 2 x MOPP).
The earth leakage current is below 75 μA which makes the units suitable for BF (body floating) applications. The excellent efficiency of up to 92% allows a high power density for the standard 2.0” x 4.0” packaging format.
The full load operating temperature range is –25°C to +55°C while it goes up to 80°C with 50% load derating.
The EMC characteristic is dedicated for applications in industrial and domestic fields. High reliability is provided by the use of industrial quality grade components and an excellent thermal management.
It makes the products an ideal solution for medical devices and for demanding safety and space critical applications.
