TPP 300-M Series
£0.00
SKU: TPP 300-M Series
The TPP 300-M series is a set of AC/DC power supplies in an encased package
style. They feature a reinforced double I/O isolation (4000 VAC) system according
to latest medical safety standards. The TPP 300-M series also has a
low leakage current of <100 μA which makes the units suitable for BF (body floating)
applications.
- 85-264VAC input
- High power-density: 300 Watt in 4.6”x2.44” package (encased)
- I/O isolation 4000 VAC rated for 250 VAC working voltage
- Certification according to IEC/EN/ES 60601-1 edition 3.2 for 2 x MOPP
- Risk management process according to ISO 14971 incl. risk management file
- Acceptance criteria for electronic assemblies acc. to IPC-A-610 Level 3
- Peak power operation up to 360 Watt for 5s
- Operating temperature –40°C to 80°C
- Active power factor correction >0.9
- Operating up to 5000m altitude
- 5-year product warranty
