TPP 15A-D Series
£0.00
SKU: TPP 15A-D
The TPP 15A-D, 15W AC-DC power supplies, feature a reinforced double I/O
isolation system according to medical safety standards IEC/EN/ES 60601-1
edition 3.2 for 2 x MOPP approved for an operating altitude of 5000 m. The
earth leakage current is below 100 μA what makes the units suitable for BF
(body floating) applications.
• High power density power supply with 85-264VAC input
• Certification according to IEC/EN/ES 60601-1 edition 3.2 for 2 x MOPP
• Low leakage current <100 μA rated for BF applications
• EMC compliance to IEC 60601-1-2 4th edition
• Risk management process according to ISO 14971 incl. risk management file
• Acceptance criteria for electronic assemblies acc. to IPC-A-610 Level 3
• Protection class II
• Operating up to 5000 m altitude
• Ready to meet ErP directive, no load power consumption <100 mW
• 5-year product warranty
