TSRN 1SM Series
£0.00
SKU: TSRN 1SM
The new TSRN 1SM series are step-down non–isolated switching regulators in compact SMD package. They are an ideal solution to replace inefficient linear regulators. The high efficiency up to 95% allows full load operation up to +55°C (+85°C with derating) ambient temperature without the need of forced air cooling. The TSRN 1SM switching regulators provide other significant features over linear regulators, i.e. better output accuracy (±2%), lower standby current of ~4 mA and no requirement of external capacitors. They are suitable for positive or negative output circuits and offer a trim input for output voltage adjustment. The high efficiency, low standby power consumption and remote On/Off function make these regulators an ideal solution for energy sensitive applications.
• Compact SMD package
• Suitable for positive & negative output circuit
• Adjustable output voltage
• Wide input up to 42 VDC
• Remote On/Off input
• Built in filter capacitors
• Operation temp. range –40°C to +85°C
• Excellent line/load regulation
• Low standby current
• 3-year product warranty
