TRI 3 Series
£0.00
SKU: TRI 3 Series
The new TRI 3 is a high isolation, regulated 3.5 Watt DC/DC converter series which comes in a compact DIP-24 package. The core characteristic of the TRI 3 series is a sophisticated reinforced isolation system which is able to withstand high test voltages (9000 VDC for 1s and 5000 VAC for 60s) and working voltages (1000 VAC rms). The new design allows to fully integrate an EN 55032 class A filter and greatly reduces the no-load power consumption. High efficiencies up to 87% allow safe operation from –40°C to +90°C without derating. All models have a wide 2:1 input voltage range and precisely regulated, isolated output voltages. With the latest IT safety certifications (IEC/EN/UL 62368-1) the TRI 3 series is the perfect choice for many demanding applications in the industrial, transportation and instrumentation sectors.
• Reinforced I/O-isolation 5000 VAC rated for 1000 VAC working voltage
• Ultra-high isolation peak voltage 9000 VDC (1s)
• Operating temperature range -40 to +90°C
• Low no-load power consumption 96 – 192 mW
• Internal EN 55032 class A filter
• High efficiency up to 87%
• 2:1 input voltage range: 4.5-9, 9-18, 18-36, 36-75 VDC
• Protection against overload, overvoltage and short circuit
• 3-year product warranty
