ECL15 Series
£0.00
SKU: ECL15 Series
The ECL15 series is a range of single, dual and triple output AC-DC power supplies that
delivers 15W of power and offers and dual output voltages ranging from 3.3V to 48V.
The ECL15 series can be supplied as PCB mount open frame (suffix -P), PCB mount
encapsulated (suffix -E), open frame chassis mount (suffix -T), or as encapsulated chassis
mount with screw terminals (suffix -S) with an optional DIN clip (suffix -SD). The ECL15 has
IEC Class II construction and a no-load input power less than 0.3W.
Regulated single outputs from 3.3V to 48VDC
Regulated dual outputs +5V +12VDC, ±12V & ±15VDC
Regulated triple outputs +5V ±12V & +5V ±15VDC
Universal input range 85-264VAC
3kVAC input to output isolation
<0.3W no load input power
EN55032 Class B conducted and radiated emissions
IEC62368-1 ITE safety agency approvals
IEC Class II insulation rating
Overvoltage, overload, and short circuit protection
-20°C to +70°C operating temperature
3 year warranty
