TDN 3WI Series
£0.00
SKU: TDN 3WI-1-1
The TDN 3WI Series comprises 3 Watt fully regulated, high performance DC/-
DC converters. They come in a compact cubical package of only 1.23 cm3. Full
load operation is reliable up tp 70°C environment temperature. With 1'600
VDC I/O-isolation voltage, external On/Off, and short current protection they
cover a wide range of application when space is limited. The input of the converters
is designed for a wide voltage range (4:1) and minimum load is not required.
The functional I/O-isolation system is designed to meet IEC/EN/UL 62368-1
(not certified) with a test voltage (60 s) of 1'600 VDC.
• Ultra compact DIP package 13.2 x 9.1 x 10.2 mm
• I/O-isolation 1‘600 VDC
• Fully regulated outputs
• Operating temperature range -40°C to +70°C without derating
• Short circuit protection
• Remote On/Off
• Designed to meet IEC/EN/UL 62368-1 (not certified)
• 3-year product warranty
