TEL 10WI Series
£0.00
SKU: TEL 10WI
The TEL 10WI series is a range of isolated 10 Watt converters which come in
an ultra compact DIP-16 metal package. The design purpose of these series
was to miniaturize low power DC/DC converters to the maximum without sacrificing
high efficiency. The TEL 10WI series sets the new standard for power density
with 3.83 W/cm³.
The TEL 10WI series offer an ultra wide 4:1 input voltage range and feature a
high efficiency of up to 86% which enables an operation temperature of up to
+70°C at full load and up to 88°C with 50% load.
The converters have an internal input filter to comply with conducted emission
EN 55032 class A. The TEL 10WI Series models are an economical solution for
space critical and cost sensitive applications in instrumentation, IT and industrial
electronics.
• Most compact 10 Watt converter in DIP-16 metal casing
• Highest power density of 3.83 W/cm³
• 6-side shielded metal case with insulated base plate
• Ultra wide 4:1 input voltage range
• High efficiency for low thermal loss
• Operating temperature range of -40°C to +88°C
• Built-in EN 55032 class A filter
• Protection against short circuit and overload
• 3-year product warranty
