TEQ-20WIR Series
£0.00
SKU: TEQ-20WIR-1
The TEQ 20WIR Series is a family of isolated high performance DC/DC converter
modules with ultra-wide 4:1 input voltage ranges which come in a rugged
metal case. These converters are suitable for a wide range of applications, but
the product is designed particularly also for industrial applications where often
no PCB mounting is possible but the module has to be mounted on a chassis.
A very high efficiency and the heatsink construction allows an operating temperature
up to +83°C with natural convection cooling without power derating
and up to +93°C with power derating. Further features include under voltage
lockout, over temperature protection and short circuit protection.
• High power block with excellent thermal convection
• Operating temperature -40°C to +93°C
• Ultra wide 4:1 input voltage range
• EN 50155 approval for railway applications
• Excellent efficiency up to 88%
• Input filter meet EN 55032 class B
• I/O isolation up to 1591 VAC
• Under voltage lock-out circuit
• Protection against overvoltage, overtemperature and short circuit
• Output LED indicator
• 3-year product warranty
