TMDC60 Series
£0.00
TMDC 60 Data sheet PStmdc60_datasheet
SKU: TMDC60
The TMDC 60 Series is a range of encapsulated high performance DC/DC
converter modules with ultra wide input voltage ranges. With a very high
efficiency of up to 92% and the use of highest grade components these 60 W
converters can be operated in an ambient temperature range of -40°C up to
70°C with full load and up to 85°C with 50% load reduction. The EMC
immunity is aligned for industrial applications and DIN-rail mount adapters are
available as option. Remote On/Off function and power good LED indicator
makes this unit to a practical and reliable DC source for any application - Fit
and forget!
• Fully encapsulated low profile plastic case
• Ultra wide 4:1 input voltage range
• Operating temperature range –40°C to +85°C
• I/O isolation 2500 VDC
• Excellent efficiency up to 92 %
• Input filter to meet EN 55022, class A
• Optional DIN-Rail mount adapter
• Power good LED indicator
• Remote on/off function
• 3-year product warranty
