TMR 3WIR Series
£0.00
SKU: TMR 3WIR
The TMR 3WIR series is a set of 3 Watt DC/DC converters in a SIP-8 metal case.
They operate up to 78°C environment temperature at full load and up to
90°C with a 50% load derating. With EN 50155 and UL 60950-1 certification,
3’000 VDC I/O-isolation voltage, external On/Off, current limitation and short
circuit protection they cover a wide range of application when space is limited.
The input of the converters is designed for a wide voltage range (4:1) and minimum
load is not required.
• Compact SIP-8 metal case
• EN 50155 railway approval
• Ultra wide 4:1 Input: 9–36, 18–75 and 43–160 VDC
• I/O-isolation 3‘000 VDC
• Fully regulated outputs
• Operating temperature range –40°C to +90°C
• Short circuit protection and current limitation
• Remote On/Off
• 3-year product warranty
