TMR 3WISM Series
£0.00
SKU: TMR 3WISM-1
The TMR 3WISM Series is a set of 3 Watt SMD DC/DC converters. They operate up to 65°C environment temperature at full load or up to 80°C with a 50% load derating. With UL 60950-1 certification, 1’500 VDC I/O-isolation voltage, external On/Off and short current protection they cover a wide range of application when space is limited. The input of the converters is designed for a wide voltage range (4:1) and minimum load is not required.
• Ultra wide 4:1 Input: 4.5–12, 9–36 and 18–75 VDC
• I/O-isolation 1‘500 VDC
• Fully regulated outputs
• Operating temperature range –40°C to + 80°C
• Protection against short circuit and overload
• Remote On/Off
• 3-year product warranty
