TSR-1 Series
£0.00
SKU: TSR-1 series
The TSR 1 series step-down switching regulators are drop-in replacement for inefficient 78xx linear regulators. A high efficiency up to 96% allows full load operation up to +60°C ambient temperature without the need of any heat-sink or forced cooling. The TSR 1 switching regulators provide other significant features over linear regulators, i.e. better output accuracy (±2%), lower standby current of 2 mA and no requirement of external capacitors. The high efficiency and low standby power consumption makes these regulators an ideal solution for many battery powered applications.
• Up to 96% efficiency – No heat-sink required
• Pin compatible with LMxx linear regulators
• SIP-package fits existing TO-220 footprint
• Built in filter capacitors
• Operation temp. range –40°C to +85°C
• Short circuit protection
• Wide input operating range
• Excellent line / load regulation
• Low standby current
• 3-year product warranty
