TOP100 Series
£0.00
SKU: TOP-100
The new TOP 100 Series AC/DC Power Supplies feature the highest power rating
in the industry standard 2.0” x 4.0” (50.8 x 101.6 mm) footprint. They can
supply up to 100 W output power with convection cooling over an industrial operating
temperature range of –25°C to +50°C. This performance could be realized
by a state of the art design providing an extremely high efficiency of >90
% which eliminates the need for a dedicated power supply cooling fan.
Also see: www.tracopower.com/info/top100_article_e1.pdf
Compliance with global safety and EMC standards qualify these power supplies
for worldwide markets. Approved for Class l and Class ll applications, these switchers
are suitable for industrial and IT systems but also for consumer products.
High reliability is provided by use of industrial quality grade components
and an excellent thermal management. This product offers an interesting power
supply solution for many space and cost critical applications in commercial and
industrial electronic equipment.
• 100 W power supply in 2.0”x 4.0“ footprint!
• Full load operation up to +50°C with convection cooling
• Highest efficiency, 90 % typ.
• EMI filter meets EN 55032, level B
• Compliance with EN 61000-3-2
• Low leakage current
• Safety class l and class ll operation
• 3-year product warranty
