ASB110 Series
£0.00
SKU: ASB110 Series
The ASB110 series is a range of complete low profile, full brick, base-plate cooled AC-DC
power supplies which require no external components. The series includes a complete
built in EMC filter and AC Fuse as well as bulk storage capacitor providing a complete
AC-DC power solution ready for installation into end applications. The ASB110 offers high
efficiency to minimise waste heat and heat sinking requirements and operates from -40°C to
+85°C on the module base-plate.
• 110W baseplate cooled
• Complete AC-DC Power Supply
• No extra components required
• -40 to +85°C baseplate temperature
• Low profile in full brick package
• High efficiency - up to 91%
• Universal input
• <0.3W no load input power
• Optional heatsink available
• Overcurrent, overvoltage and overtemperature protection
• 3 year warranty
