PAE1500 Series (ORing FET)
£0.00
SKU: PAE1500 Series (ORing FET)
PAE1500 (ORing FET) Series is a single output 1500W power supply, with built in OR'ing FETS. 7 models with DC outputs programmable from 0-105% for both Voltage and Current. Nominal outputs from 12V to 60V DC
Features:
Universal AC input / Full range
Programmable output Voltage (0% ~ 105%)
Programmable output Current (0% ~ 105%)
Built-in ORing FET
Built-in IC to isolate communication
Forced current sharing at parallel operation (Refer to pg. 5 for connection diagram) Constant current limit
Selectable +5V / 0.5A or +9V / 0.3A auxiliary output
Global control via RS232
Remote setting multiple PSU via RS232, RS485 & I²C
Power OK signal
Remote ON / OFF, Remote sense function
Protection: OVP, OLP, OTP, Fan failure
Built-in active PFC Function
