TBA 2 Series
£0.00
SKU: TBA 2 Series
The TBA 2 is a 2 Watt DC/DC SIP converter series which is specifically
designed to offer a low-cost solution with no concession on quality and lifetime.
The new design improves on the industry standard features and offers an
integrated continuous short circuit protection circuit, an operating temperature
range from –40°C to 80°C without derating and I/O-isolation of 1’500 VDC. It
offers a broad application range in any space and cost critical application.
• Continuous short circuit protection
• I/O isolation: 1’500 VDC
• Operating temperature range
-40 to +80 °C without derating
• Input voltage ranges (±10%): 5, 12, 24 VDC
• High efficiency up to 84%
• SIP-7 package
• Unregulated outputs
• 3-year product warranty
