TEC 2 Series
£0.00
SKU: TEC 2 Series
TEC 2 is a new series with the design purpose to improve the prevalent 2 Watt
SIP-8 DC/DC converters in terms of cost, efficiency and performance. The latest
technology and components enable an increase in efficiency by more than
20%. With the reduction of thermal loss, the operating temperature range can
be expanded from -40°C to +95°C. The converters are fully regulated over 0 -
100% load (no minimum load is required). The low input range is extended
from 4.5 to 13.2 VDC while models are also available with the standard 2:1 input
ranges (see TEC 2WI series for 4:1 input ranges). The functional isolation
system is designed to meet IEC/EN/UL 62368-1 (not certified) with 1600 VDC
test voltage.
• Compact SIP-8 package
• I/O-isolation voltage 1‘600 VDC
• Fully regulated outputs
• Operating temp range –40°C to +95°C
• Continuous short circuit protection
• Remote On/Off
• Designed to meet IEC/EN/UL 62368-1 (not certified)
• 3-year product warranty
