TEC 3UI Series
£0.00
SKU: TEC 3UI Series
The TEC 3UI is a series of isolated DC/DC converters with ultra-wide input range.
This new converter generation is designed to seamlessly replace and offer
an alternative to existing 2:1 and 4:1 input converter series, ensuring no compromise
on performance or cost-effectiveness. With an input voltage ranging
from 9 to 75 VDC, the TEC 3UI covers a variety of standard bus voltages, minimizing
the need for multiple model variants in an application. All models are
equipped with short circuit protection, over current limitation, under voltage lockout
and feature remote control functions. The converters operate reliably up
to a maximum temperature of +90°C, with an approved operating temperature
range of -40°C to +80°C according to IEC/EN/UL 62368-1 and can operate at
altitudes up to 5000 meters. The compact SIP8 plastic case makes the TEC
3UI series ideal for space-constrained applications. Available as both single
and dual output models, these converters are suitable for various industrial applications.
• Compact SIP8 plastic case
• Ultra-wide input range: 9 VDC to 75 VDC
• Certification according to IEC/EN/UL 62368-1
• Approved operating temperature from -40°C to +80°C
• I/O isolation 2000 VDC
• Operating up to 5000m altitude
• Short circuit protection and over current limitation
• Under voltage lockout
• Remote ON/OFF
• 3-year product warranty
