TEL 10 Series
£0.00
SKU: TEL 10
The TEL 10 series is a range of isolated 10 Watt DC/DC converters which
come in a ultra compact DIP-16 metal package. The design purpose of these
series was to miniaturized low power DC/DC converters to the maximum without
sacrificing high efficiency. The TEL 10 series sets the new standart for power
density with 3.83 W/cm³.
The TEL 10 series offers a wide 2:1 input voltage range and features a high efficiency
of up to 88% which enables an operation temperature of up to +70°C
at full load and up to 85°C with 50% load.
The converters have an internal input filter to comply with conducted emission
EN 55032 class A. The TEL 10 Series models feature an overall economical solution
for space critical and cost sensitive applications in instrumentation, IT
and industrial electronics.
• Most compact 10 Watt converter in DIP-16 metal casing
• Highest power density of 3.83 W/cm³
• 6-side shielded metal case with insulated base plate
• Wide 2:1 input voltage range
• High efficiency for low thermal loss
• Operating temperature range of -40°C to +88°C
• Built-in EN 55032 class A filter
• Current limitation and protection against short circuit
• 3-year product warranty
