TEL 12 Series
£0.00
SKU: TEL 12
The TEL 12 is a 12 Watt DC/DC converter series which comes in an ultra compact
DIP-16 metal package. The design purpose was to miniaturized low power
DC/DC converters to the maximum without sacrificing high efficiency. They solidify
the new standard for power density with 3,61 W/cm3 and effectively double
the power density compared to 12 Watt converters in DIP-24 package. The
TEL 12 and offers a wide 2:1 input voltage range and features a high efficiency
of up to 88% which enables an operation temperature of up to +65°C at full
load and up to 85°C with 50% load. The converters also have an internal input
filter to comply with conducted emission standard EN 55032 class A. Overall
they feature an economical solution for space critical and cost sensitive applications
in instrumentation, IT and industrial electronics.
• Ultra compact 12 Watt converter in DIP-16 metal casing
• Highest power density of 3,61W/cm3
• 6-side shielded metal case with insulated baseplate
• Wide 2:1 input voltage range
• High efficiency (up to 88%) for low thermal loss
• Operating temperature range -40°C to +88°C
• Built-In EN 55032 class A filter
• Protection against short circuit
• 3-year product warranty
