TEL 15WIN-HS Series
£0.00
SKU: TEL 15WIN-HS Series
The TEL 15WIN-HS is a series of isolated 15 Watt converters which come in an
ultra compact DIP-16 metal package with a special heatsink-case design for
extended temperature capabilities. The design purpose of this series was to
maximize temperature capabilities within the standard DIP-16 footprint. The
TEL 15WIN-HS offers a wide 4:1 input voltage range and features a high efficiency
of up to 87% which together with the integrated heatsink casing enables
an operation temperature of up to +70°C at full load and up to 85°C with
50% load. The converters also have an internal input filter to comply with conducted
emission standard EN 55032 class A. It's an economical solution for
space critical and cost sensitive applications in instrumentation, IT and industrial
electronics where operating temperature range is critical factor.
• Ultra compact 15 Watt converter in DIP-16 metal casing
• Special heatsink-case design for maximized temperature capabilities
• Operating temperature range -40°C to +70°C without derating
• Wide 4:1 input voltage ranges: 9-36, 18-75 VDC
• High efficiency (up to 87%) for low thermal loss
• 6-side shielded metal case with insulated baseplate
• Built-In EN 55032 class A filter (conducted)
• Protection against short circuit
• 3-year product warranty
