TEN 15 Series
£0.00
SKU: TEN 15
The TEN 15 series is a family of high performance 15W DC/DC converters in a com-pact 2” x 1” low profile package with industry standard footprint. A high efficiency allows a wide operating temperature range of –40°C to +85°C. A built-in EMI filter is built in to meet EN 55022, class A without any external components.
Further standard features include over voltage protection and short-circuit protection. Typical applications for these converters are battery operated equipment, instrumentation, distributed power architectures in communication and industrial electronics, everywhere where isolated, tightly regulated voltages are required.
• Wide 2:1 input range
• High efficiency up to 88%
• Extended operating temperature range – 40°C to +85°C
• Indefinite short circuit protection
• I/O isolation 1500 VDC
• Input filter to meet EN 55022, Class A and FCC, level A without external components
• Industry standard footprint
• Shielded metal case with insulated baseplate
• 3-year product warranty
