TEN 30UIR Series
£0.00
SKU: TEN 30UIR Series
The TEN 30UIR is a series of high-performance DC/DC converters with an ultra-
wide 12:1 input voltage range and a power output of 30 watt. The TEN 30-
UIR comes in a compact, fully encapsulated 2”x1” housing for highest reliability
and effective cooling. Thanks to its dedicated holdup capacitor connection, the
TEN 30UIR meets extended holdup-time requirements without the need for bulky
input capacitors. The TEN 30UIR is EN 50155 certified for rolling stock applications,
EN 61373 certified for resistance against mechanical shock and vibration
and EN 45545-2 certified for fire behavior. The TEN 30UIR also comes
with IEC/EN/UL 62368-1 safety approvals for use in a wide range of demanding
industrial applications.
• Compact 2”x1” housing
• Ultra-wide 12:1 input voltage range: 9–75, 14–160 VDC
• –40°C up to +70°C natural convection cooling without derating
• EN 50155, EN 45545-2 and EN 61373 certified
• Dedicated holdup capacitor connection
• Fully encapsulated
• 3000VDC I/O isolation
• Remote on/off and trim function
• Protection against short-circuit (SCP), overvoltage (OVP) and overtemperature (OTP)
• 3-year product warranty
