TEN 3N Series
£0.00
SKU: TEN 3N Series
The TEN 3N Series is a drop in replacement of the prevalent TEN 3 Series. The
up-to date design enables a cost reduction without any compromise to reliability
and function. They come with an internal filter to meet EN55032 class A without
external components. Increased EMC immunity and extended operating
temperature range of –40°C to +85°C make these converters an ideal solution
for cost critical but demanding applications. With the standard pinning it is a
drop in replacement for common 3 Watt converters in DIP24 package.
• Wide 2:1 input range
• Input filter to meet EN 55032, class A and FCC, level A without external components
• Extended operating temperature range –40°C to +85°C
• Models with 1’500 VDC and 3’000 VDC I/O isolation (functional insulation)
• High reliability, MTBF >1.0 Mio. h
• 3-year product warranty
