TEN 40E Series
£0.00
SKU: TEN 40E Series
The TEN 40E is rounding out Traco Power’s existing 40 Watt product range.
Driven by current market trends this series was developed to maximize quality
and cost efficiency in one product. Due to a new design approach the TEN 40E
thus offers a cost efficient solution with not only no concession on quality or reliability
but even improved specifications compared to its predecessor. It comes
in a standard 2” x 1” metal package with a 2:1 input voltage range. High efficiencies
of up to 93% allow for an operating temperature range (natural convection)
of -40 to +70°C without power derating (model dependent). Certified
according to the latest IT standard (IEC/EN/UL 62368-1) and equipped with
additional features like remote on/off function and protection against short circuit,
overvoltage and over temperature the TEN 40E series is suitable for many
industrial applications.
• Developed to maximize quality in a cost efficient design
• Excellent temperature capabilities
• 2” x 1” metal package (6-side shielded)
• Wide 2:1 input voltage range: 9-18, 18-36, 36-75 VDC
• Minimal heat development due to high efficiencies up to 93%
• Operating temperature range -40 to +85°C
• 1600 VDC I/O-isolation
• Remote On/Off and Trim function
• Protection against short circuit, overvoltage and overtemperature
• 3-year product warranty
