TEN 40WI Series
£0.00
SKU: TEN 40WI
The TEN 40WI series is a family of high performance 40W DC/DC converter
modules featuring ultra wide 4:1 input voltage ranges in a compact low profile
case with industry-standard footprint. A very high efficiency allows an operating
temperature range of –40°C to 85°C. Further standard features include remote
On/Off, output voltage trimming, over voltage protection, under voltage
lockout, over temperature and short circuit protection. Typical applications for
these products are battery operated equipment and distributed power
architectures in communication and industrial electronics, everywhere where
isolated, tightly regulated voltages are required and space is limited on the
PCB.
• High power density: 40W in 2”x2”x0.4” metal package
• Ultra wide 4:1 input voltage range
• Very high efficiency up to 89 %
• No minimum load required for single output models
• Over temperature protection
• Under voltage lockout
• Remote On/Off
• Shielded metal case with insulated baseplate
• Optional heat-sink
• 3-year product warranty
