TEN 40WIE Series
£0.00
SKU: TEN 40WIE Series
The TEN 40WIE is rounding out Traco Power’s existing 40 Watt product range.
Driven by current market trends this series was developed to maximize quality
and cost efficiency in one product. Due to a new design approach the TEN 40-
WIE thus offers a cost efficient solution with not only no concession on quality
or reliability but even improved specifications compared to its predecessor. It
comes in a standard 2” x 1” metal package with a 4:1 input voltage range. High
efficiencies of up to 93% allow for an operating temperature range (natural convection)
of -40 to +70°C without power derating (model dependent). Certified
according to the latest IT standard (IEC/EN/UL 62368-1) and equipped with
additional features like remote on/off function and protection against short circuit,
overvoltage and over temperature the TEN 40WIE series is suitable for
many industrial applications.
• Developed to maximize quality in a cost efficient design
• Excellent temperature capabilities
• 2” x 1” metal package (6-side shielded)
• Wide 4:1 input voltage range: 9-36, 18-75 VDC
• Minimal heat development due to high efficiencies up to 93%
• Operating temperature range -40 to +85°C
• 1600 VDC I/O-isolation
• Remote On/Off and Trim function
• Protection against short circuit, overvoltage and overtemperature
• 3-year product warranty
