TEN 40WIRH Series
£0.00
SKU: TEN 40WIRH Series
The TEN 40WIRH is a series of 40 watt railway-certified DC/DC converters with
reinforced I/O isolation for highest reliability in harsh environments. The proven
and certified design guarantees highest resistance against thermal shocks, moisture,
mechanical shocks, and vibration. The TEN 40WIRH comes with additional
EN 62368-1 safety approvals for IT equipment and EN 45545-2 certification
for fire behavior. Thanks to its favorable operating temperature range of -
40°C up to +70°C (depending on the model), the TEN 40WIRH presents a first
choice for demanding applications.
• Fully encapsulated 2”x1” package
• 3000 VAC I/O isolation (reinforced)
• 4:1 input voltage range: 36 – 160 VDC
• EN 50155 and EN 61373 certified
• Internal class A EMI filter
• -40°C up to +70°C operating temperature
• EN 45545-2 fire behavior
• Remote on/off function
• Undervoltage lockout (UVLO), short-circuit protection (SCP), overtemperature protection (OTP), and overvoltage protection (OVP)
• 3-year product warranty
