TEN 60 Series
£0.00
SKU: TEN 60
The TEN 60 series is a family of high performance 60W DC/DC converter
modules with wide 2:1 input voltage ranges in a low profile case with
industry-standard 2" x 2" footprint. High efficiency allows for an operating
temperature range of –40°C to 75°C. Built-in filters for both input and output
minimizes the need for external filtering. Further standard features include
remote On/Off, output voltage trimming, over voltage protection, under voltage
lockout and short circuit protection. Typical applications for these products are
battery operated equipment and distributed power architectures in
communication and industrial electronics.
• Wide 2:1 input voltage range
• High efficiency up to 91%
• No minimum load required
• Over temperature protection
• Under voltage lock-out circuit
• Remote On/Off
• 3-year product warranty
