TEN 8WI Series
£0.00
SKU: TEN 8WI
The TEN 8WI series is a family of high performance 8 Watt dc/dc converter modules
featuring ultra wide 4:1 input voltage ranges in a DIP-24 package with industry-
standard footprint. Input voltages up to 160 VDC, excellent EMC characteristics
and EN 50155 approval make this product the best choice for many
demanding applications in railroad and transportation systems. Further standard
features include remote On/Off, over voltage protection, under voltage lockout
and short circuit protection. Typical applications for these converters are
also in wireless networks, telecom/datacom, industry control systems and measurement
equipment.
• Ultra wide 4:1 input range up to 160 VDC
• Certified for Railway applications (EN 50155)
• Operating temperature range -40°C to + 85°C
• Input under voltage lockout
• I/O isolation 1500 VDC
• Input filter to meet EN 55022 class A
• Remote On/Off
• 3-year product warranty
