TEN20 WIRH Series
£0.00
SKU: TEN20 WIRH Series
The TEN 20WIRH is a series of 20 watt railway-certified DC/DC converters with
reinforced I/O isolation for highest reliability in harsh environments. The proven
and certified design guarantees highest resistance against thermal shocks, moisture,
mechanical shocks, and vibration. The TEN 20WIRH comes with additional
EN 62368-1 safety approvals for IT equipment and EN 45545-2 certification
for fire behavior. Thanks to its favorable operating temperature range of -
40°C to +75°C without derating (depending on the model), the TEN 20WIRH
presents a first choice for demanding applications.
• Fully encapsulated 1”x1.6” package
• 3000 VAC I/O isolation (reinforced)
• 4:1 input voltage range: 36 – 160 VDC
• EN 50155 and EN 61373 certified
• Internal class A EMI filter
• -40°C up to +75°C without derating
• EN 45545-2 fire behavior
• Remote on/off function
• Undervoltage lockout (UVLO), short-circuit protection (SCP), overtemperature protection (OTP), and overvoltage protection (OVP)
• 3-year product warranty
