TEP 100WIRCM Series
£0.00
SKU: TEP 100WIRCM Series
The TEP 100WIRCM Series is a family of isolated high performance DC/DC converter
modules with ultra-wide 4:1 input voltage ranges which come in a rugged,
sealed industry standard half brick package. A very high efficiency allows full
power operation without forced air cooling at 60°C This temperature can be increased
to 70°C with optional mounted heatsink or up to 85°C when mounted
on an iron base plate. The very wide input voltage range make these converters
interesting solution for battery operated systems. Typical applications are in telecom/
datacom, industry control and railway systems for on board power distribution.
• Chassis mount with screw terminal block
• Ultra wide 4:1 input voltage ranges 9–36, 18–75, 43–160 VDC
• EN 50155 approval for railway applications
• Very high efficiency up to 93%
• No minimum load
• Soft start
• Adjustable output voltage +10/-20%
• Sense line
• Remote On/Off input
• Under voltage lock-out circuit
• 3-year product warranty
