TEP 100WIRCMF Series
£0.00
SKU: TEP 100WIRCMF Series
The TEP 100WIRCMF Series is a family of isolated high performance DC/DC converter modules with ultra-wide 4:1 input voltage ranges. They come in chassis mount version with screw terminal block. A very high efficiency allows full power operation without forced air cooling at 60°C. The very wide input voltage range make these converters interesting solution for battery operated systems. Typical applications are in telecom/datacom, industry control and railway systems for on board power distribution.
• Chassis mount with screw terminal block
• Ultra wide 4:1 input voltage ranges 9–36, 18–75, 43–160 VDC
• EN 50155 approval for railway applications
• Very high efficiency up to 93%
• No minimum load
• Soft start
• Adjustable output voltage +10/-20%
• Sense line
• Remote On/Off input
• Under voltage lock-out circuit
• 3-year product warranty
